FV-71B14

1. High-quality aluminum alloy casting, lightweight, non-corrosive;2. Large output torque;3. Smooth ...

Speed ratio: Single-stage speed ratio ranges from 7 to 100, and double-stage speed ratio ranges from 240 to 2800.

Input power: 0.06KW to 5.9KW

Input methods: Hole type, Shaft type, Hole-axle type, Double-axle type

Output method: Hole-type output, shaft output

Deceleration installation method: B3, B6, B7, B8, V5, V6

Motor wiring box positions: 0°, 90°, 180°, 270°

Motor frame size: 56, 63, 71, 80, 90, 100, 112, 132, 160, 56C, 56H, 140TC, 180TCSpeed ratio: Single-stage speed ratio ranges from 7 to 100, and double-stage speed ratio ranges from 240 to 2800.

Input power: 0.06KW to 5.9KW

Input methods: Hole type, Shaft type, Hole-axle type, Double-axle type

Output method: Hole-type output, shaft output

Deceleration installation method: B3, B6, B7, B8, V5, V6

Motor wiring box positions: 0°, 90°, 180°, 270°

Motor frame size: 56, 63, 71, 80, 90, 100, 112, 132, 160, 56C, 56H, 140TC, 180TC

Online Contact

product details

Outline reference diagram

1. High-quality aluminum alloy casting, lightweight, non-corrosive;

2. Large output torque;

3. Smooth transmission, low noise;

4. Good heat dissipation performance;

5. Beautiful and durable product;

6. Good interchangeability of installation and connection dimensions with mainstream products from abroad.
